We know full well that for many out there, the ultimate trail bike needs to possess the agility and responsiveness that comes with 27.5 wheels. We tend to agree, which is why we developed the S-Works Stumpjumper 27.5. It reflects everything that we've learned over the years, and in our eyes, represents the pinnacle of trail performance.
Starting at the carbon layup, it features our highest-end FACT 11m for an ultra-lightweight, strong, and stiff construction. The carbon molding process also allowed us to revolutionize how you carry your trail essentials with the all-new SWAT Door found at the down tube. This compartment will fit a tube, a tool, and pump without rattling or compromising the structural integrity of the frame. Further improving the ride, you'll also find an aggressive, trail-eating geometry that features ridiculously short chainstays, a roomy top tube, a low bottom bracket, a slacked out front end, and our proprietary Rx Trail Tune at the shock.
For this S-Works model, we outfitted it with a build spec that spares no expense. This means that it's loaded with a full SRAM XX1 Eagle groupset, SRAM Guide RS brakes, Ohlins front and rear suspension, and hand-built Roval Carbon wheels. So with this Stumpjumper, you have a bike that, without a doubt, is ready for anything on the trail.
- FACT 11m carbon fiber Trail Chassis with Stumpjumper FSR full carbon rear end blends stiffness with light weight to form the pinnacle of efficiency, while fully enclosed cable routing and an integrated SWAT™ Door create exceptional handling and zero-hassle storage.
- The Ohlins RXF 36 fork was designed to be the gold standard in frontend suspension. It operates off of a three-chamber air spring design (two positive and one negative), and it utilizes proprietary TTX damping technology. Combined, this allows both parallel and separated oil flow that controls the overall pressure levels.
- The XX1 Eagle drivetrain is the pinnacle of shifting performance, floating through the 12-speed cassette with crisp, precise shifts.
|Frame||S-Works FACT 11m, full carbon chassis and rear end, 27.5 Trail Geometry, SWAT Door integration, PF30 BB, fully enclosed internal cable routing, ManFu link, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 150mm of travel|
|Fork||Ohlins RFX 36 fork, 27.5, air spring, TTX22 damper, 150mm of travel, 15mm x 110mm thru-axle|
|Rear Shock||Custom Ohlins STX, Single-Tube design, Rx Trail Tune, 3rd Chamber air spring technology, AUTOSAG, adjustable compression & rebound damping, 197x48mm|
Front: 15x110mm thru-axle
Rear: 12x148mm thru-axle
|Rims/Wheels||Roval Carbon wheels|
|Tires||Butcher, GRID casing, Gripton, 2Bliss Ready, 27.5 x 2.6"|
|Crankset||SRAM XX1 Eagle, Boost 148, 170mm crankarm, 30mm spindle|
|Bottom Bracket||SRAM PF30|
|Chain||SRAM X01 Eagle, 12-speed w/ PowerLock|
|Rear Derailleur||SRAM XX1 Eagle, 12-speed|
|Cassette/Rear Cogs||SRAM X01 Eagle, 12-speed, 10-50t|
|Shifters||SRAM XX1 Eagle, trigger, 12-speed|
|Handlebars||Specialized Trail, FACT carbon, 6-degree upsweep, 8-degree backsweep, 27mm rise, 780mm, 31.8mm|
|Tape/Grips||Specialized Sip Grip, half-waffle, S/M: regular thickness, L/XL: XL thickness|
|Stem||Syntace F109, 6-degree rise, 31.8mm clamp|
SRAM Guide RS carbon, hydraulic disc, organic pads, carbon lever, Guide S4 4-piston caliper, Front: 200/180mm rotor
Rear: 180/160mm rotor
|Saddle||Body Geometry Henge Expert, hollow Ti rails, 143mm|
|Seat Post||Command Post IRcc, 12-position micro-height adjustable, alien head design, bottom mount cable routing, remote SRL lever, 30.9mm, S: 100mm, M/L/XL: 125mm of travel|
* Subject to change without notice.
|Option||Barcode||Manufacturer's Part Number|
|Satin Gloss Carbon/Hyper Green / Small||888818318599||93318-0002|
|Satin Gloss Carbon/Hyper Green / Medium||888818318582||93318-0003|
|Satin Gloss Carbon/Hyper Green / Large||888818318100||93318-0004|
|Satin Gloss Carbon/Hyper Green / X-Large||888818315413||93318-0005|
